Page 49Vortex8 User Manual
Version 1.2
10.2 Specs for the Vortex8
10. Specifications
Material
Aluminium/Technopolymer
Light Source
RGBW LED
Colour Range
CCT: 2200 - 15000K, PLUS/MINUS GREEN,
HUE/SATURATION, XY, GELS, DIRECT
RGBW, EFFECTS
CRI
Typical 95
TLCI
Typical 95
Beam Angle, SPOT Lens
20° (Half Peak Angle)
Tilt Angle
360°
Photometrics
3200K:
68,200 lx / 6,340 fc @ 1m / 3.3
26,200 lx / 2,430 fc @ 2m / 6.6
12,700 lx / 1,180 fc @ 3m / 9.8
7,400 lx / 690 fc @ 4m / 13.1
4,800 lx / 450 fc @ 5m / 19.4
3,400 lx / 320 fc @ 6m / 19.7
5600K:
73,500 lx / 6,830 fc @ 1m / 3.3
28,600 lx / 2,660 fc @ 2m / 6.6
13,900 lx / 1,290 fc @ 3m / 9.8
8,000 lx / 740 fc @ 4m / 13.1
5,200 lx / 480 fc @ 5m / 19.4
3,700 lx / 340 fc @ 6m / 19.7
Mounting
8x 3/8” Threaded Insert Rigging Points
Yoke
Removable quick release yoke
Filter Rails
2 Filter Rails for Secondary Lenses,
Diusers, Accessories
User interface
High Precision Digital Magnetic Encoder,
Backlit Keypad, Colour LCD Display
Dimming
0-100% with High Resolution, Super-
Smooth Low End Mode
High Speed Capability
Over 5000fps Flicker Free in High Speed
Mode
Synchronization
Sync Input for Triggering and Syncing to
Camera Shutter
Max Ambient Temperature
40°C
Cooling
Low noise variable speed fans
Estimated LED Lifespan
50,000hrs (L70)
Input (AC)
100-240V AC, 50/60Hz, Max 6.6A. Neutrik
PowerConTrue connector
Input (DC)
48V DC, Max 13.75A, Can run at 100%
brightness on DC input
Protection Class
IP65
Weight
13.7kg / 30lb (Excluding Yoke)
1.98kg / 4.4lb (Yoke weight)
Dimensions
690 x 380 x 121mm / 27.2” x 15” x 4.8”
(Excluding Yoke)
831 x 551 x 164mm / 32.7” x 21.7” x 6.4”
(Including Yoke)
Warranty
3 Years on Fixtures, 12 Months on
Accessories (5 Years registered)
Certifications
CE, RCM, FCC. Pending: ETC
Control
On-Board Interface, DMX via standard 5-
pin XLR connectors, Wired Remote Control
Accessory, Integrated Lumen radio Timo
Two with Bluetooth, Ethernet, USB Type A
Includes
Vortex8 650W Colour, Yoke, Power cable,
Flat diuser
Product Code
K-CSV-8-ESS
