Hardware Information D-3
AUX1 Connector Pin Assignments
The AUX1 connector has the following pin assignments as shown in
Table D-1.
AUX2 Connector Pin Assignments
The AUX2 connector has the following pin assignments as shown in
Table D-2.
Table D-1: AUX1 connector pin assignments.
Pin Signal I/O
1 AUX1 Left Channel In
2 Analog Ground —
3 Analog Ground —
4 AUX1 Right Channel In
Table D-2: AUX2 connector pin assignments.
Pin Signal I/O
1 AUX2 Left Channel In
2 Analog Ground —
3 Analog Ground —
4 AUX2 Right Channel In
