Hardware Information D-7
Gold Finch Connector Pin Assignments
The Gold Finch connector has the following pin descriptions as shown
in Table D-7.
IDE Connector Pin Assignments
The IDE connector has the following pin assignments shown in
Table D-8.
Table D-7: Gold Finch connector pin assignments.
Pin Description Pin Description
1 EMUR 2 AGND
3 EMUL 4 AGND
5 KEYED 6 AGND
7NC 8NC
Table D-8: IDE connector pin assignments.
Pin Description Pin Description
1 ResetB 2 Digital Ground
3 DD7 4 DD8
5 DD6 6 DD9
7 DD5 8 DD10
9 DD4 10 DD11
11 DD3 12 DD12
13 DD2 14 DD13
15 DD1 16 DD14
17 DD0 18 DD15
19 Digital Ground 20 NC
