Hardware Information D-5
DRAM Upgrade Connector Pin Assignments
There are two DRAM Upgrade connectors on your card. Each has a
different set of pin assignments as shown in Table D-5 and Table D-6.
Table D-5: 24-pin DRAM Upgrade connector pin assignments.
Pin Description Pin Description
1VCC 2VCC
3SDO 4SD1
5SD2 6SD3
7SD4 8SD5
9SD6 10SD7
11 Digital Ground 12 Digital Ground
13 WRB 14 SMRAS
15 Digital Ground 16 Digital Ground
17 SMA19 18 SMA0
19 SMA1 20 SMA2
21 SMA3 22 SMA20
23 NC 24 VCC
