D-6 Hardware Information
Table D-6: 26-pin DRAM Upgrade connector pin assignments.
Pin Description Pin Description
1 RAMDIS 2 VCC
3SD15 4SD14
5SD13 6SD12
7SD11 8SD10
9SD9 10SD8
11 Digital Ground 12 Digital Ground
13 SMCAS 14 MODE
15 Digital Ground 16 Digital Ground
17 Digital Ground 18 Digital Ground
19 SMA16 20 SMA7
21 SMA6 22 SMA5
23 SMA4 24 SMA18
25 VCC 26 VCC
