Hardware Information D-11
Telephone Answering Device Connector Pin
Assignments
The Telephone Answering Device connector has the following pin
assignments as shown in Table D-14.
Wave Blaster Connector Pin Assignments
The Wave Blaster connector has the following pin descriptions as
shown in Table D-15.
Table D-15: Wave Blaster connector pin assignments.
Table D-14: Telephone Answering Device connector pin assignments.
Pin Description I/O
1 Mono Line-In from modem. In
2 Analog Ground
3 Analog Ground
4 Microphone output to modem. Out
Pin Description Pin Description
1 Digital Ground 2 NC
3 Digital Ground 4 MIDI Output
5 Digital Ground 6 VCC
7 Digital Ground 8 MIDI Input
9 Digital Ground 10 VCC
11 Digital Ground 12 NC
13 NC 14 VCC
15 Analog Ground 16 NC
