D-4 Hardware Information
CD Audio Connector Pin Assignments
Your audio card has two types of CD Audio connectors.
The CD Audio connector has the following pin assignments as
shown in Table D-3.
The CD Audio connector has the following pin assignments as
shown in Table D-4.
Table D-3: CD Audio connector pin assignments.
Pin Signal I/O
1 Analog Ground —
2 CD Left Channel In
3 Analog Ground —
4 CD Right Channel In
Table D-4: CD Audio connector pin assignments.
Pin Signal I/O
1 CD Left Channel In
2 Analog Ground —
3 Analog Ground —
4 CD Right Channel In
