Commercial Power Amplifiers Crestron AMP-2210S/3210S
AMP-2210S/3210S Connectors, Controls & Indicators (Continued)
#
CONNECTORS*,
CONTROLS &
INDICATORS
DESCRIPTION
10
ON/REMOTE/OFF
(1) 3-position slide switch;
Selects between all channels powered on, off,
or remote controlled
11
110-240V~50/60Hz
120W MAX
(1) IEC C14 male chassis plug, main power
input;
Mates with removable power cord (included)
* Interface connectors for INPUT, SPEAKER OUTPUT, and REMOTE ports are provided with the
unit.
8 Commercial Power Amplifiers: AMP-2210S/3210S Operations & Installation Guide – DOC. 7251A
