2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2
program to run. If CFAUTORUN is disabled, then the user must either press the
SW-R button on the front panel or issue a program reset through the Viewport to
switch programs.
Other Compact-Flash-Related Functions
In addition to the previous topics that are impacted by compact flash availability,
other Viewport command functions-including Erase Program, Erase Web Pages, and
Send Generic Files-permit you to choose between internal flash and compact flash
when selecting programs/files for processing.
A new SIMPL Windows command File | Copy Output to Compact Flash copies a
compiled SIMPL Windows program (SPZ) file) to a compact flash reader/writer on a
PC. Click Browse to locate the SPZ file; select the drive letter of the CF
reader/writer from the drop-down list. Click OK to copy the file.
Advanced Console Commands
The SIMPL Windows online help file provides a full listing of console commands
that are valid for 2-Series control systems. You can access the AV2/PRO2 console in
a variety of ways: via a serial connection (RS-232) with a PC, over Ethernet via the
LAN port, or through Telnet, among many other methods. It is also possible to issue
console commands through logic, by adding a Console symbol to the SIMPL
Windows program.
The Console symbol is only visible in the Symbol Library when “Special” is selected
as the Symbol Set. Click Edit | Preferences. In the Symbol Set area of the General
tab, select Special as shown below.
"SIMPL Windows Preferences" Window
Console commands are provided for advanced programmers. However, most
functions and commands can be selected from the various Viewport menus.
NOTE: For more information on console commands, refer to the 2-Series Console
Commands Reference Guide, (latest version of DOC. 6002) available from the
Downloads | Product Manuals section of the Crestron website (www.crestron.com).
Console Commands for Compact Flash
The following commands have been added to enable processing functions for
compact flash files/programs:
CFAUTORUN - Enable the program to autoboot from compact flash.
26 • Integrated Dual Bus Control System: AV2 & PRO2 Operations Guide - DOC. 5957A

Crestron AV2 Specifications

General

Internal memory	64 GB
Internal memory type	SDRAM
Internal storage capacity	0.004 GB
AC input voltage	100-250 V
AC input frequency	50 - 60 Hz
Power consumption (max)	50 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Housing material	Metal

Weight and Dimensions

Depth	261.9 mm
Width	432.6 mm
Height	90.4 mm
Weight	3220 g
