Crestron AV2 User Manual

Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System
Specifications
Specifications for the AV2 and PRO2 are given in the following table.
AV2/PRO2 2-Series Integrated Control System Specifications
SPECIFICATION DETAILS
CPU 32-Bit Motorola ColdFire
®
Processor
Processor Speed 257 MIPS (Dhrystone 2.1 Benchmark)
Onboard Memory 36MB (4MB flash, 32MB DRAM, 256KB NVRAM)
1
Expandable Memory Compact Flash Slot (up to 4GB) accepts standard
Type II Compact Flash or IBM Microdrive
®
Dual Bus Architecture
Y-BUS (Optional on AV2)
40 Mb/s Parallel Communications
Z-BUS
300 Mb/s Parallel Communications
3 Expansion Card Slots
2
1 Expansion Card Slot
3
Ethernet (Optional Z-BUS cards) Dynamic/Static IP Addressing
Full Duplex TCP/IP and UDP/IP
Built-in Firewall for Ultimate Security (Dual Port Only)
Built-in Network Address Translator (Dual Port Only)
Built-in Router – Built-in Web Server (Dual Port Only)
Ports/Connectors
4
NET
COMPUTER
INFRARED – SERIAL OUTPUT
I/O
RELAY OUTPUT
COM (A through F)
1 – Cresnet 4-wire interface (Expandable via Cresnet
Poll Accelerator)
5
2 – DB9F PC interface (front and rear panel access)
8 – Simultaneous one-way IR or serial output
8 – Programmable digital/analog inputs & digital
outputs
8 – Normally open, isolated relays (MOV suppression)
6 – DB9 bidirectional serial ports (RS-232, -422, -485);
ports C - F are Cresnet Poll Accelerator ready
5
Power Requirements 100-240 VAC, 2.4 A, 50/60 Hz
Internal Universal Power Supply
Network Power Fuse Rating 4A, 250V (1¼” x ¼” Slow Blow Fuse Series)
50 watts (DC) available for Cresnet devices
Reset Buttons HWR - Initiates system hardware reset
SWR – Program Restart / Program Bypass
LCD Display (PRO2 only) Reverse mode (yellow on black) LCD backlight;
2 lines, up to 40 characters per line.
Environmental Temperature & 41° to 113°F (5° to 45°C)
Humidity 10% to 90% RH (non-condensing)
Dimensions & Weight Height: 3.47 in (8.81 cm)
Width: 19.0 in (48.26 cm) – with ears
17.03 in (43.24 cm) – without ears
Depth: 9.69 in (24.61 cm)
Weight: 7.10 lb (3.22 kg) – AV2 with line cord
8.00 lb (3.62 kg) – PRO2 with line cord
1 For more information on system memory usage, refer to “On-Board Memory” on page 13.
2 40 Mb/s parallel communications and supports current and enhanced Crestron control cards.
3 Optional Z-BUS Cards: Single port 10/100 Ethernet, Dual Port WAN-LAN-10/100 Ethernet, or
Dual Port WAN-LAN-10/100 Ethernet-USB
4 For more information on controls, ports, and indicators, see “Physical Description” on page 4.
5 Cresnet Accelerator increases effective network speed, fan-out, and device addresses by a factor of
8 for each Poll Accelerator added to the system.
Operations Guide - DOC. 5957A Integrated Dual Bus Control System: AV2 & PRO2 • 3

Crestron AV2 Specifications

General

Internal memory	64 GB
Internal memory type	SDRAM
Internal storage capacity	0.004 GB
AC input voltage	100-250 V
AC input frequency	50 - 60 Hz
Power consumption (max)	50 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Housing material	Metal

Weight and Dimensions

Depth	261.9 mm
Width	432.6 mm
Height	90.4 mm
Weight	3220 g
