Crestron AV2 User Manual

Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System
Integrated Dual Bus Control
System: AV2 & PRO2
Introduction
Features and Functions
Crestron’s AV2 and PRO2 2-Series Integrated Control Processors are designed for
medium to large home and commercial network systems. Like all Crestron control
processors, the AV2 and PRO2 units house the control system software program and
provide connectivity for communication and control of all devices on the network.
High performance front panel diagnostics and monitoring make the PRO2 ideal for
sophisticated control of even the most complex audio, video, lighting, security, and
HVAC systems. The AV2 is functionally identical to the PRO2, with the exception
that it does not provide the front panel diagnostics and monitoring. Both units are
fully expandable with one Z-BUS; three Y-BUS slots are standard on the PRO2 and
optional on the AV2.
Functional Summary
•
Powered by 2-Series Control Engine
• 36 MB of Internal Memory*
• 4 GB Expansion Slot for Type II Compact Flash and IBM
Microdrive
®
Hard Disk Drive
• Front Panel Diagnostics and Monitoring (PRO2 only)
• 8 IR/Serial Ports
• 8 Isolated Relay Ports
• 8 I/O Versiports
• 6 RS-232/422/485 Ports
• 2 RS-232 Computer Ports (1 front; 1 rear)
• 1 Cresnet Port
• Supports SIMPL
™
Windows
®
& SIMPL+
™
• 1 Z-Bus Expansion Slot
•
3 Y-Bus Ex
p
ansion Slots
(
O
p
tional on AV2
)
*
For more information on internal memory usage, refer to “On-Board Memory” on Page 13.
Operations Guide - DOC. 5957A Integrated Dual Bus Control System: AV2 & PRO2 • 1

Crestron AV2 Specifications

General

Internal memory	64 GB
Internal memory type	SDRAM
Internal storage capacity	0.004 GB
AC input voltage	100-250 V
AC input frequency	50 - 60 Hz
Power consumption (max)	50 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Housing material	Metal

Weight and Dimensions

Depth	261.9 mm
Width	432.6 mm
Height	90.4 mm
Weight	3220 g
