Crestron DMPS-100/200/300-C/300-C-AEC DigitalMedia Presentation System
Operations Guide – DOC. 7219D DigitalMedia Presentation Systems: DMPS-100/200/300-C/300-C-AEC • 11
DMPS-100/200/300-C Specifications (Continued)
SPECIFICATION DETAILS
Communications
Ethernet 10/100/1000 Mbps, auto-switching,
auto-negotiating, auto-discovery, full/half
duplex, TCP/IP, UDP/IP, CIP, DHCP, Private
Network mode, SSL, SNMP, IPv4, RSTP,
SMTP e-mail client, Web Server;
Installer setup via Crestron Toolbox;
Supports all e-Control
®
, Crestron Mobile, Fusion
RV and RoomView applications
Cresnet
®
Cresnet master mode
DigitalMedia DM 8G+, HDCP, EDID, CEC, PoDM, HDBaseT
compliant
HDMI HDMI, HDCP, EDID, CEC
USB USB service port for computer console, USB
HID signal routing over DM
RS-232 2-way device control and monitoring up to
115.2k baud with hardware and software
handshaking
IR/Serial 1-way device control via infrared up to 1.2 MHz,
or serial TTL/RS-232 (0-5 volts) up to 115.2k
baud; supports CNXRMIRD IR Receiver
1
Ethernet Switch
Multi-port switch with Private Network mode;
Provides (1) onboard 10/100/1000BASE-T
Gigabit Ethernet port, and multiple remote
10BASE-T/100BASE-TX Ethernet ports via
select outboard DM devices, plus internal
Ethernet ports for the control processor,
switcher, and audio DSP
Video
Switcher Auto-detecting multi-format digital/analog
source inputs, 7x4 matrix switcher, HDMI and
DM 8G+ outputs, QuickSwitch HD technology
Input Signal Types
(DMPS-100-C)
HDMI (Inputs 1-4), RGB
2
(Inputs 2-4),
composite/S-video/component (Input 4)
Input Signal Types
(DMPS-200-C)
HDMI (Inputs 1-5), RGB
2
(Inputs 3-5),
composite/S-video/component (Input 5),
DM 8G+ (Input 6)
Input Signal Types
(DMPS-300-C)
HDMI (Inputs 1-5), RGB
2
(Inputs 3-5),
composite/S-video/component (Input 5),
DM 8G+ (Inputs 6 & 7)
Output Signal Types
(DMPS-100-C)
HDMI , DM 8G+ (Output 1)
Output Signal Types
(DMPS-200-C)
HDMI (Output 1), DM 8G+ (Output 2)
Output Signal Types
(DMPS-300-C)
HDMI (Outputs 1 & 2), DM 8G+ (Outputs
3 & 4)
(Continued on following page)
