16 • DigitalMedia Presentation Systems: DMPS-100/200/300-C/300-C-AEC Operations Guide – DOC. 7219D
DMPS-100/200/300-C Specifications (Continued)
SPECIFICATION DETAILS
Audio
Typical of analog line outputs
with DSP: (Continued)
GEQ Presets 1 thru 10
PEQ Center Frequencies 5 to 24,000 Hz per band
PEQ Gain -36.0 to +24.0 dB per band
PEQ Bandwidth 0.02 to 3.50 octaves per band
PEQ Types Peaking EQ, High Pass, Low Pass, High
Shelf, Low Shelf, Notch
Delay 0.0 to 85.3 ms
Frequency Response 20 Hz to 20 kHz ±0.5 dB (digital source),
20 Hz to 20 kHz ±0.5 dB (analog line
source), 20 Hz to 20 kHz ±0.7 dB
(microphone source)
S/N Ratio >108 dB (digital source), >103 dB (analog
line source), 1 kHz, A-weighted
THD+N <0.002% (digital source), <0.005% (analog
line source), <0.05% (microphone source),
20 Hz to 20 kHz
Stereo Separation >108 dB (digital source)
>103 dB (analog source)
Channel Separation >103 dB
AEC reference output
(internal):
Volume -80 to +20 dB, adjustable from 0% to 100%,
plus mute
Bass ±12.0 dB
Treble ±12.0 dB
Source Mix Gain -80.0 to 0.0 dB, plus mute and balance
Codec Mix Gain (x2) -80.0 to 0.0 dB, plus mute and balance
Equalization 10-band graphic + 2-band parametric
GEQ Center Frequencies 31.5, 63, 125, 250, 500, 1k, 2k, 4k, 8k, 16k
Hz
GEQ Gain ±12.0 dB per band
GEQ Presets 1 thru 10
PEQ Center Frequencies 5 to 24000 Hz per band
PEQ Gain -36.0 to +24.0 dB per band
PEQ Bandwidth 0.02 to 3.50 octaves per band
PEQ Types Peaking EQ, High Pass, Low Pass, High
Shelf, Low Shelf, Notch
Typical of HDMI/DM outputs:
Output Signal Types HDMI (Outputs 1 & 2),
DM 8G+/HDBaseT (Outputs 3 & 4)
Formats Dolby Digital, Dolby Digital EX, DTS,
DTS-ES, DTS 96/24, up to 8-channel PCM
(Continued on following page)
