Crestron TPMC-8X-GA Isys
®
8.4” WiFi Touch Screen
The setup menu provides access to all basic functions and parameters. It is divided
into Setup, Ethernet, Battery, Standby, Power Down, WiFi Status and Docking
Station Status sections. There are also buttons for Save & Reboot, Shut Down and
Exit.
NOTE: To allow the touch screen to upload projects, standby is disabled until
approximately five minutes after the project is loaded.
To exit the setup menu and return to the program, touch Exit, located at the bottom
of the setup menu. To save any changes and reboot the touch screen, touch Save &
Reboot, located at the bottom of the setup menu. Use the Shut Down button to turn
off the touch screen.
Setup Menu Details
The setup menu allows configuration of the touch screen’s settings for security,
touch screen calibration, runtime project, audio, embedded applications, diagnostics
and hard button programming. The setup menu also has a button that will toggle the
on-screen keyboard on and off.
Security
The Security button opens the “Security Setup” window, which allows the user to
change the username and password of the system account, setup and close network
connections, setup a proxy server and clear Internet browser temporary files, history
and cookies.
NOTE: To use the on-screen keyboard for security settings, touch Keyboard on the
setup menu before touching Security.
“Security Setup” Window
Touch Setup Connections… to open the “Network Connections” window. This
window is used to map to a network drive. A mapped network drive permits easy
access to embedded application files (Word, Excel, PowerPoint, etc.) and provides a
Operations Guide – DOC. 7078C Isys
®
8.4” WiFi Touch Screen: TPMC-8X-GA • 15
