MA-2402 Service Manual130445-1 Rev. A
Exploded View Parts 7-9
©2000 Crown International, Inc.
Item Quantity Description Part # (CPN)
7.6 Fan Assembly
Refer to figure 7.5 for Exploded View
Item Quantity Description Part # (CPN)
Figure 7.5 MA-2402 Fan Assembly
1
2
3
4
5
6
7
2
1
2
1
1
1
1
6-32 X 5/16 UNDERCUT FLTHD MSCR
BRACKET, FAN
6-32 X .312 PAN HD T15 TT TYPE W
XMOTOR
FAN BLADE, 4.5 INCH CCW
LBL, 1A/05A FUSE REPLACEMENT
LBL, FAN VOLTAGE DOMESTIC
C7062-0
D8439-8
C9491-9
SEE SECTION 3
C9938-9
D7340-9
127516-1
