Crown Macro-Tech MA-2402 - Standard PIP Assembly

MA-2402 Service Manual 130445-1 Rev. A
7-10 Exploded View Parts
©2000 Crown International, Inc.
Item Quantity Description Part # (CPN)
Item Quantity Description Part # (CPN)
7.7 Standard PIP Assembly
Refer to figure 7.6 for Exploded View
Figure 7.6 Standard PIP Assembly
1
2
3
4
5
6
2
1
1
2
2
4
#8 X 1/4 #6 PNHD PH BZ
PWA, PIP2FXQ
PANEL, PIP2FXQ
PHONE JACK HARDWARE INCLD. W/ PHONE JACK
PHONE JACK HARDWARE INCLD. W/ PHONE JACK
M3 X .5 X 7MM PN HD BLK/NYLOK
C 7161-0
127210-1
127234-1
A10330-9
