Cryo-con Model 24C Appendix F: Configuration Scripts
<Loop>
<!------------ Loop 1 --------------->
<Command>Loop 1:SetPt 250</Command>
<Command>Loop 1:Type MAN</Command>
<Query>Loop 1:Type?</Query>
<Command>Loop 1:Pman 20</Command>
<Query>Loop 1:Pman?</Query>
<Command>control</Command>
<Query>Loop 1:Outp?</Query>
<Command>Stop</Command>
</Loop>
<PIDTable>
<!Download to table 6>
<Command>PIDTABLE 5:table</Command>
<!Table Name>
<Command>LOOP1 Htr</Command>
<!Table Entries>
<Command>310.00 1.60 160.00 40.00 Default HI</Command>>
<Command>280.00 1.50 150.00 30.00 Default HI</Command>
<Command>260.00 1.40 140.00 30.00 Default HI</Command>
<Command>240.00 1.30 130.00 30.00 Default HI</Command>
<Command>220.00 1.20 120.00 30.00 Default HI</Command>
<Command>200.00 1.10 110.00 20.00 Default HI</Command>
<Command>180.00 1.00 100.00 20.00 ChA MID</Command>
<Command>160.00 0.90 90.00 20.00 ChA MID</Command>
<Command>140.00 0.80 80.00 20.00 ChA MID</Command>
<Command>120.00 0.70 70.00 10.00 ChA MID</Command>
<Command>100.00 0.60 60.00 10.00 ChA MID</Command>
<Command>80.00 0.50 50.00 10.00 ChB MID</Command>
<Command>60.00 0.40 40.00 10.00 ChB Low</Command>
<Command>40.00 0.30 30.00 0.00 ChB Low</Command>
<Command>20.00 0.20 20.00 0.00 ChB Low</Command>
<Command>;</Command>
</PIDTable>
171
