Cryo-con Model 24C Specifications, Features and Functions
Specifications, Features and Functions
Specification Summary
User Interface
Display Type: 40 character by 8 line TFT LCD with LED backlight.
Number of Inputs Displayed: Four.
Keypad: Sealed Silicon Rubber.
Temperature Display: Six significant digits, autoranged.
Display Update Rate: 0.5 Seconds.
Display Units: K, C, F or native sensor units.
Display Resolution: User selectable to seven significant digits.
Input Channels
There are four input channels, each of which may be independently configured
for any of the supported sensor types.
Sensor Connection: 4-wire differential. Screw-in type DIN-6 circular.
Connections are described in the Sensor Connections section.
Supported Sensors Include:
Type Excitation
Temperature
Range
Example
Silicon diode
10mA DC
1.4 to 475K
Cryo-con S900
SI-440, 430, 410
Lakeshore DT-670, 470
Platinum RTD
Constant-Current, 1mA AC 14 to 1200K
Cryo-con CP-100
Cryo-con GP-100
Cryo-con XP-100
Cryo-con XP-1K
Cernox™ Constant-Voltage AC 100mK to 420K Lakeshore, all types
Ruthenium-Oxide
Constant-Voltage AC 100mK to 273K SI RO-600, SI RO-105
Carbon-Ceramic
Constant-Voltage AC 1.0K to 300K TMi-A1
Rhodium-Iron Constant-Current, 1mA AC 1.4 to 800K Oxford PHZ 0002
Germanium
Thermistor
Constant-Voltage AC 100mK to 100K AdSem, Inc.
Silicon
Thermistor
Constant-Voltage AC 1.0K to 400K AdSem, Inc.
Thermistor
Constant-Voltage AC 193 - 523K Measurement Specialties
CLTS Constant-current, 100uA AC 4 to 325K Vishay CLTS-2B
Thermocouple
None 1.4 to 1500K All thermocouple type
Table 5: Supported Sensor Types
