Cryo-con Model 24C Appendix G: Sensor Data Tables
Cernox™
Cernox™ temperature sensors do not
follow a standard calibration curve. Data
shown here is for typical sensors.
The Model 24C supports Cernox™ using
a 10mV or less Constant-Voltage AC
excitation. Please refer to the section
titled "Voltage Bias Selection"
Lakeshore Cernox™ CX-1010
Name: User Supplied Config: ACR 10mV
Below 2.0K 3.0mV
T(K) Ohms
W/K
0.1 21389 -558110
0.2 4401.6 -38756
0.3 2322.4 -10788
0.4 1604.7 -4765.9
0.5 1248.2 -2665.2
1 662.43 -514.88
1.4 518.97 -251.77
2 413.26 -124.05
3 328.95 -58.036
4.2 277.32 -32.209
6 234.44 -17.816
10 187.11 -8.063
20 138.79 -3.057
30 115.38 -1.819
40 100.32 -1.252
50 89.551 -0.929
77.35 70.837 -0.510
100 61.180 -0.358
150 47.782 -0.202
200 39.666 -0.130
250 34.236 -0.090
300 30.392 -0.065
Lakeshore Cernox™ CX-1030
Name: User Supplied Config: ACR 10mV
Below 2.0K 3.0mV
T(K) Ohms
W/K
0.3 31312 -357490
0.4 13507 -89651
0.5 7855.7 -34613
1 2355.1 -3265.2
1.4 1540.1 -1264.9
2 1058.4 -509.26
3 740.78 -199.11
4.2 574.20 -97.344
6 451.41 -48.174
10 331.67 -19.042
20 225.19 -6.258
30 179.12 -3.453
40 151.29 -2.249
50 132.34 -1.601
77.35 101.16 -0.820
100 85.940 -0.552
150 65.864 -0.295
200 54.228 -0.184
250 46.664 -0.124
300 41.420 -0.088
350 37.621 -0.065
400 34.779 -0.050
420 33.839 -0.045
