Cryo-con Model 24C Front Panel Menu Operation
User Configurations Menu
The User Configurations Menu is displayed by pressing the Config key. It is used to
save or restore up to four instrument setups. Each setup saves the entire state of the
Model 24C including setpoints, heater configurations, input channel data etc.
User Configurations Menu
1
Pressing the Enter key saves the instrument setup to
the selected configuration number.
2
ecall
Pressing the Enter key restores a saved
configuration.
Table 19: User Configurations Menu
Saving a User Configuration
In the Config menu, navigate to the Save field of the desired configuration. Press the
Enter key to execute the save.
Restoring a User Configuration
First, press the Config key and navigate to the Recall field of the desired
configuration. Press the Enter key to execute the restore.
59
