Appendix G: Sensor Data Tables
Silicon Diode
Silicon diode sensors offer good
sensitivity over a wide temperature range
and are reasonably interchangeable.
Use in magnetic fields is not
recommended.
Silicon diode sensors use a constant-
current DC excitation of 10A.
Cryo-con S900 Silicon Diode
Name: Cryocon S900 Configuration: Diode
T(K) Volts mV/K
1.4 1.63864 -36.56
4.2 1.53960 -33.91
10 1.35568 -26.04
20 1.18193 -11.34
30 1.10465 -3.12
50 1.07188 -1.46
77.35 1.02511 -1.69
100 0.98615 -1.85
150 0.88988 -2.03
200 0.78311 -2.17
250 0.67124 -2.28
300 0.55674 -2.36
355 0.42759 -2.33
400 0.32161 -2.38
450 0.20231 -2.37
500 0.09077 -2.12
Cryo-con S800 Silicon Diode
Name: Cryocon S800 Configuration: Diode
T(K) Volts mV/K
1.4 1.87515 -36.86
4.2 1.75099 -49.16
10 1.47130 -43.45
20 1.18867 -15.93
30 1.10594 -3.90
50 1.07079 -1.47
77.35 1.02356 -1.86
100 0.98170 -1.85
150 0.88365 -2.03
200 0.77887 -2.13
250 0.67067 -2.20
300 0.55955 -2.22
355 0.44124 -2.10
385 0.37611 -2.26
Scientific Instruments SI-430 and SI-440
Name: SI 430 Diode Configuration: Diode
Name: SI 440 Diode Configuration: Diode
T(K) Volts mV/K
1.4 1.63864 -36.56
4.2 1.53960 -33.91
10 1.36317 -26.04
20 1.17370 -11.34
30 1.10343 -3.12
50 1.07399 -1.46
77.35 1.02511 -1.69
100 0.98740 -1.85
150 0.89011 -2.03
200 0.78272 -2.17
250 0.67085 -2.28
300 0.55665 -2.36
355 0.42759 -2.33
400 0.32161 -2.38
450 0.20231 -2.37
500 0.09077 -2.12
