Cryo-con Model 24C Front Panel Operation
The Front Panel Display
Home Status Displays
At the top of the instrument’s menu tree are the home status displays. They can be
selected from anywhere in
the instrument’s menu tree
by pressing the Home
key.
The Home display is easily
configured to show only
desired data. There are
four zones, each of which
may be independently configured.
Pressing the Display key will list the configuration of each zone.
To change the contents of
a zone, scroll to the
desired zone and press
the Enter key. This will
result in a display of all
possible selections for the
selected zone. A summary
of the important selections
is given below:
Temperature
Displays an input channel temperature in 2x font. Above the temperature is the input
channel indicator, name string and alarm status. Below is the sensor type and
excitation level.
Loop Status Displays
These displays show the current status of a selected control loop. The control loop's
input temperature is shown in 2x font. Above is the loop and channel indicator, the
input channel's name string and alarm status. Below in 1x font is the loop's setpoint,
heater range and percent-of-full-scale output power.
Input Channel Statistics Display
The Channel A, B, C and D statistics displays show the selected input channel
temperature, the slope of the temperature history, the minimum and maximum
temperatures.
The slope of the temperature history (M) is given in Display Units per Minute.
When any of the statistics pages are displayed, pressing the Enter key will reset the
accumulation.
1A Sample Holder 2B First Stage
251.445K 296.845K
300.000K 1-Off-Low 100.000K 2-Off-Low
C: Second Stage D:Rad Shield
251.445K 296.845K
RO-600 RuOx 10uV R500 RuOx 1.0mV
46
Home Zone Configuration Menu
Zone 1 Loop 1 Status
Zone 2 Loop 2 Status
Zone 3 ChC Temperature
Zone 4 ChD Temperature
