Cryo-con Model 24C Appendix G: Sensor Data Tables
Platinum RTD
Platinum RTD sensors feature high
stability, low magnetic field dependence
and excellent interchangeability. They
conform to the DIN43760 standard curve.
Platinum RTD, DIN43760 and IEC751
Name: Pt100 385 Configuration: PTC100
Name: Pt1K 385 Configuration: PTC1K
T(K) Ohms
W/K
20 2.2913 0.085
30 3.6596 0.191
50 9.3865 0.360
77.35 20.380 0.423
100 29.989 0.423
150 50.788 0.409
200 71.011 0.400
250 90.845 0.393
300 110.354 0.387
400 148.640 0.383
500 185.668 0.378
600 221.535 0.372
700 256.243 0.366
800 289.789 0.360
900 324.302 0.318
1123 390.47 0.293
Rhodium-Iron
Rhodium-Iron sensors feature high
stability, low magnetic field dependence
and reasonable interchangeability.
The Model 24C supports them with
1.0mA Constant-Current AC excitation.
Rhodium-Iron 27W
Name: RhFe 27 1mA Configuration: PTC100
T(K) Ohms
W/K
1.4 1.5204 0.178
4.2 1.9577 0.135
10 2.5634 0.081
20 3.1632 0.046
30 3.5786 0.040
50 4.5902 0.064
77.4 6.8341 0.096
100 9.1375 0.106
150 14.463 0.105
200 19.641 0.102
250 24.686 0.101
300 29.697 0.101
350 34.731 0.101
400 39.824 0.103
Cryogenic Linear
Temperature Sensor (CLTS)
CLTS sensors are inexpensive and offer
excellent interchangeability. The Model
24C supports them with 100uA Constant-
Current AC excitation.
CLTS-2B
Name: CLTS Configuration: CLTS
T(K) Ohms
W/K
4.15 220 0.24
45 229.73 0.24
75 236.91 0.24
105 244.08 0.24
195 265.6 0.24
250 278.75 0.24
273.15 295.71 0.24
300 290.71 0.24
175
