Cryo-con Model 24C
Index of Figures
Figure 1: 4122-030 Rack Mount Kit............................................................9
Figure 2: 4034-032 Rack Mount Kit............................................................10
Figure 3: Model 24C Rear Panel Layout....................................................37
Figure 4: Model 24C Front Panel Layout...................................................41
Figure 5: Thermocouple Module.................................................................95
Figure 6: Thermocouple Switches..............................................................95
Figure 7: Proper Assembly of the Input Connector ....................................181
Figure 8: Diode and Resistor Sensor Connections.....................................182
Figure 9: RS-232 Null Modem Cable..........................................................184
v
