Cryo-con Model 24C Front Panel Menu Operation
Integrator gain values range from zero to 10,000. The units of this term are Seconds.
A value of zero turns the integration function off.
Derivative gain values have units of inverse Seconds and may have values from zero
to 1000. A value of zero turns the Derivative control function off.
The Pman field is only used when the heater output is in manual control mode. The
value is represented in percent of full-scale output power (Watts) and may have
values from zero to 100%.
i Note: The Model 24C expresses heater output values in terms
of percent of full-scale output power. The actual power, in Watts,
applied to the load is proportional to the square-root of output
current.
Control Source Input Channel Enumeration
The input filed selects the control loop source input. Any input channel may be
selected.
Control Loop Range Enumeration, Default: Low
The Range field selects the full-scale output for the selected control loop.
56
