10. Technical specifications
10.1 Tank
Unit TP 35 TP 60 TP 100
Total capacity Litres 35 60 99
Working capacity Litres 35 60 98
Maximum working gauge pressure Bar 0,5 0,5 0,5
Static duration of use Days 35 60 75
Weight when empty, without control head kg 17,6 24 31
Weight when empty, with control head kg 19,8 26,4 33,5
Weight when full of nitrogen, with control head kg 48 74,5 113,5
Daily rate of evaporation
With insulating stopper
Litres/day 0,7 0,7 0,7
With control head
Litres/day 1 1 1,3
Time required for pressure to build up (1)
Tank ½ full
min & sec 3 min 50 4 min 5 min
Tank ¼ full
8 min 8 min 10 min
Delivery rate (2) l/min 2,4 3,5 5,2
Ambient temperature (3) °C 20 20 20
Storage temperature °C <50 <50 <50
Dimensions (H1 and H2) mm 853/668 1080/896 1213/1029
Total internal height mm 580 815 945
External diameter mm 468 468 510
(1) from 0 to 0.5 bar, pressure-building open
(2) maximum at P = 0.5 bar (3) operating temperature when sheltered from direct sunlight
