CryopAL TP-35 - Control Head

35
Figure 10-1:
Dimensions (in
mm).
10.2 Control head
Feature Principal characteristics
Nitrogen level: Measured by a mechanical level indicator (float)
Nitrogen pressure Pressure gauge (graduated from 0 to 1.6 bar)
Controller Integral
Safety 2 valves calibrated to 0.5 bar
Manual valves Filling / withdrawal
Vent / overflow
