Operating Instruction and Documentation
CSL640/641
- 15 – TES1518/E
3.6 Electrical Circuit Diagrams (Connection Diagrams)
The earth connections should comply with local regulations
Make sure that all connections and contacts are secure and in place
Check that all wiring and electrical components are in place before commissioning
Do not allow commissioning at a site not suitable for the equipment.
1. Connection diagrams and electrical components
All diagrams have been drawn by us to the best of our knowledge. We take no responsibility for
diagrams other than these to be used with the equipment. This is especially the case of diagrams
drawn up by second parties.
2. Checking the diagrams
The diagrams do not always refer to serial components. Some of these components such as switches,
thermostats and motors might not be shown. Even with careful testing, we cannot rule out problems
occurring with the systems. We cannot take any responsibility for misuse of the guidelines on
installation of the equipment. Any request for changes to the diagrams in order to enable the equipment
to function better will be at the request of a surplus charge. Improvements by third parties cannot be
accepted.
Equipment: CSL 640/641
Diagram No. CSL 640/641
3. Safety checks and means of protection
All connections have been made under the code VDEO 100/0113 and the accident prevention code
V8641 for electrical equipment.
The following tests have been completed:
1. Isolation check on the switchboard and control boards according to VDEO/5 73
2. Checking the functions of the applied safety features by indirect touching of components
according to the code VDEO100g/7/75 par 22.
3. Functions and component checks according to code VDE560/11 87
Other safety codes have been adhered to:
1. Protection against direct contact code VDEO100/5. 73. Par 4
2. Protection against indirect contact code VDE=100/5. 73. Par 5
These connection diagrams are the property of the manufacturers. They should not be used for any
other purpose or given to a third party without the authority of the manufacturers
