Operating Instruction and Documentation
CSL640/641
- 45 – TES1518/E
• During lifting or lowering the operator must observe the vehicle to ensure that the vehicle
and the lift are functioning correctly.
• Installation of the standard-mobile column lift in hazardous or dangerous locations such as
washing bays is dangerous and is not allowed.
• During lifting or lowering the vehicle it must be observed by the operator.
5. Operating Instructions
The Safety Regulations must be observed and adhered to while working with the
automotive lift. Read the safety regulations in chapter 4 carefully before working with
the lift!
5.1 Lifting the vehicle
• Drive vehicle onto the centre of the lift in the longitudinal and transverse directions.
Each wheel must rest completely on its respective platform. Failure to correctly
position the vehicle may result in the vehicle falling from the lift.
• Secure the vehicle against rolling away put into gear and apply the handbrake.
• Check the dangerous places around and on the lift and be sure that there are no objects or
people in the immediate area surrounding the lift or on the lift.
• Switch on the control system and switch the main switch to position”1” (pic.1)
• Lift the vehicle to the required working height by pushing the ‘lift’ button (pic.2).
Main Switch
Pic. 1
Pic. 2
Button “Lifting”
