CryptOn CSL640 User Manual

Operating Instruction and Documentation
CSL640/641
- 60 – TES1518/E
• Push ” up” button until the vent screw at the top of master cylinder is
accessible. If the lift does not work activate bypass switch (see pic. 5) in addition with the
“up” button until the lift is at the relevant height.
• Open vent screw (cylinder screw with copper ring), located at upper side in guide bush of the
master cylinder. Unscrew until oil comes out of the bore-hole for deaerating (Do not unscrew
vent screw completely).
• Shut vent screw immediately and fasten it.
• If the ratchets of the lift engage before oil comes out of the vent screw, shut the vent screw
and lift the lift with button ”up” until the ratchet is no longer engaged.
• Afterwards repeat deaerating as described until oil comes out of the ventilating screw.
• Carry out equalisation of the platforms as described in the „operating instructions” chapter.
• Raise the lift to a height of 1500 mm.
• Before the lift is doweled to the ground, the quality of the ground must be checked. For an
existing concrete floor the dowels have to be chosen according to pic. 16, if the ground is
covered with floor tiles, the dowels have to be chosen according to
pic. 17.
• CRYPTON demands dowels that are recommended on pages 64 and 65 of this manual.
• Check adjustment of the ground plates again. Drill the holes into the ground through the
corresponding holes in the ground plates. Clean the holes and insert dowels.
• Adjust lift according to separate instruction. The manufacturer demands Liebig safety-dowels
type B 12 or equal dowels from another manufacturer.
• Adjust the lift by screwing the adjusting screws at the base plate of the sliding end and the
fixed pivot end. Adjust one platform until it is level first and then adjust the second platform
so that it is even with the first.
• Tighten the dowels (masonry bolts) with a dynamometric key or torque wrench
(M = 70 Nm)
Each dowel (masonry bolt) must be tightened to a torque of 70 Nm. Otherwise the
normal function of the lift can not be guaranteed.
• Lift and lower the automotive lift repeatedly. Tighten dowels with dynamometric key or torque
wrench again (M = 70 Nm) and check hydraulic lines are tightly sealed.
9.4 Initiation
Before the initiation a security check must be performed. Therefore use form: First
security check.
If the lift is installed by a competent person, he will perform this security check. If the operator
installs the lift by himself, he must instruct a competent person to perform the security check.
The competent should confirm the faultless function of the lift in the installation record. The form
for the security check should be completed before the lift is allowed to be used.
Please send the filled installation record to the manufacturer after installation.
9.5 Changing of the place of installation
If the place of installation must be changed, the new place has to be prepared according to
these regulations. The changing of the location must be performed according to the following
schedule:
• Loosen dowels.
• Lift the lift without any load to a height of 500 mm.
• Put a wooden bar with a sufficient length (longer than platform’s width) under the central
axes of the each of the scissors.
• Lower the lift until the central axes rests on the wooden bar and the ground plates begin to
lift of the ground.
