Operating Instruction and Documentation
CSL640/641
- 46 – TES1518/E
5.2 Lowering the vehicle
Attention! Your lift is equipped with the CE-Stop safety system, during lowering the lift
will stop a short distance above the floor.
Check the danger areas around and on the lift and be sure that there are no objects or
people in the immediate area around the lift, or on the lift. To complete the lowering
process push the ‘lower’ button (see pic 3) again. An alarm will sound to caution that the
lift is completing its lowering function.
• Lower the vehicle to the required working height or until the platforms are in their lowest
position.
Button for “Lowering” the lift
Pic. 3
5.3 Lowering onto the safety ratchet (latch)
To perform the play detector, the platforms must be lowered onto the safety ratchets (latches).
• Raise the lift to the working height.
• Push the button shown in pic 4 to lower the lift into safety ratchets. The lift will slowly lower
itself to the next ratchet (latch) position.
• Continue to push this button until the hydraulic system is no longer pressurised.
Button for “lowering” to next ratchet Position.
Pic. 4
• The lift must be raised slightly before lowering to free the platforms from the ratchets
(latches). Once the platforms are free of the ratchets, the lift can be lowered once again.
• Press the button “Lifting”
