Operating Instruction and Documentation
CSL640/641
- 59 – TES1518/E
8. Security check
The security check is necessary to guarantee the safety of the lift during use. It has to
be performed in the following cases:
1. Before the initial operation, after the first installation.
Use the form ”First security check”.
2. In regular intervals after the initial operation, at least annually.
Use the form ”Regular security check”.
3. Every time the construction of that particular lift has been changed.
Use the form ”Extraordinary security check”.
The first and regular security check must be performed by a competent person. It is
also recommended that a service be carried out during these checks.
After the construction of the lift has been changed (for example changing the lifting
height or capacity) and after serious maintenance works (welding on load bearing
parts) an extraordinary security check must be performed by an expert.
This manual contains a form with a schedule for the security checks. Please use the appropriate
form for the particular security check. The forms should remain in this manual after they have
been filled out.
9. Installation and Initiation
9.1 Installation of the lift
The standard installation requires the command unit to be installed at the front right side of the lift
(refer to data sheet). The command can be installed in other areas if necessary but special
hydraulic hoses are needed.
9.2 Regulations for the installation
• The installation of the lift is performed by trained technicians of the manufacturer or its
distribution partner. If the operator can provide trained mechanics, he can install the lift himself.
The installation has to be done according to this regulation.
• For the installation a concrete floor with a specified thickness (see foundation plan) and a
quality of at least C20/25 has to be provided. If these requirements cannot be fulfilled a
foundation according to the foundation plan must be made. The area must be completely even.
Foundations located outside or in areas that are vulnerable to frost must be made frost proof.
• An electric supply 3~/N + PE, 400 V, 50 Hz has to be provided by the customer. The connection
is located in the command unit.
• A compressed air supply with an inside diameter of 6 mm must be provided at the command
unit. The pressure must be 6 bar (max. 10 bar).
• All cable ducts have to be equipped with protective coverings to prevent accidental damage.
9.3 Erection and doweling (Masonry bolting) the lift
• Install the lift according to the data sheet and the foundation plan, also see TES1532
• Install command unit at its specified place and connect it with air and power supply.
• Fill the hydraulic oil, approximately 10 litres. A high quality hydraulic oil is
recommended, its viscosity should be 32 cst. (HLP 32 OEST Company)
• Connect hydraulic and pneumatic hoses and electrical wires between command unit and lift
in accordance with plan:
