DIGIAIR PRO
PATH AVAILABLE GRADES WHAT’S IN THE BOX PART NUMBER
Radio 4G SP2
DigiAir Pro, serial cable & small
aerial
CS.51.R2
LAN SP2
DigiAir Pro, serial cable, Ethernet
Cable & LAN connector adaptor
CS.51.L2
Wi-Fi (coming soon) SP2
DigiAir Pro, serial cable, Ethernet
Cable, Wi-Fi board & Wi-Fi
module enclosure
CS.51.W2
GRADESHIFT PRO
PATH AVAILABLE GRADES WHAT’S IN THE BOX PART NUMBER
LAN/Radio 4G
DP2
DP2+
DP3
GradeShift Pro, serial cable, single
T-bar aerial, Ethernet Cable, & LAN
connector adaptor
CS.53.LR2
CS.53.LR2P
CS.53.LR3
Radio 4G/ Radio 4G
DP2
DP2+
DP3
DP4
GradeShift Pro, secondary radio
module, serial cable, Dual T-bar
aerial
CS.53.RR2
CS.53.RR2P
CS.53.RR3
CS.53.RR4
13
Figure 11 - DUALCOM PRO RANGE
Dimensions
75 mm (h) x 119mm (w) x 15mm (d) or 75mm (h) x 119mm (w) x
32mm (d) with secondary radio module
Weight 113g excluding aerial
Temperature -10 C° to + 55 C°
Humidity Humidity – 90% non-condensing
Mounting Via fixing points under main cover
Warranty 5 years
Power Requirement 10 - 36 Volts DC
Current Consumption From 35mA to 175mA dependant on variant
Radio Path 2G, 3G, 4G
Aerial 50 ohm (nominal) on MMCX socket
Operation Method Store and forward
CIE Interconnections Input triggering (standardised parallel), RS232, RS485, TTL
RCT Protocols SIA
Input Terminals Max +30v, Min 0 volts DC (reference supply 0v supply) 100k
Low Battery 7.6V DC +/- 0.5 VDC
User Serviceable Parts There are no serviceable parts within the DualCom Pro Range
Environmental Class II
Applicable Standards
Suitable for use in alarm systems complying to:
EN50131-1:2006+A2:2017
EN50131-10:2014 Type Y
EN50136-1:2012+A1:2018 SP1,SP2,SP3,SP4,DP1,DP2,DP3,DP4
EN50130-5
Emissions Standard – 2014/53/EU (RED)
PD6662:2017 / PD6669:2017
ATS Classification: EN50136 ATS5/DP4 Max
ATS 5 parameters: D3/M3/T4/S2/I3/A3
SPECIFICATIONS
