GENERAL DESCRIPTION
Page 2-16
Table 5. ZP Single Stage Specifi cations
Table 6. ZP Cascade Specifi cations
Single Stage -34°C to 190°C
Cooling Performance Heating Performance
with Empty Chamber in Minutes from: with Empty Chamber in Minutes from:
24°C 24°C -34°C
Model -18°C -34°C 93°C 190°C 24°C
ZP-8-2-H/AC 6 18 10 30 10
ZP-16-2-H/AC 8 22 15 50 12
ZP-32-2-H/AC 10 28 20 72 15
ZP-44-2-H/AC 15 40 20 60 15
ZP-64-2-H/AC 20 50 25 75 20
Cascade -70°C to 190°C
Cooling Performance Cooling Heating Performance
with Empty Chamber in Minutes from: Rate ² with Empty Chamber in Minutes from:
24°C 85°C °C / min 24°C -34°C -68°C
Model -18°C -34°C -40°C -54°C -68°C -40°C 93°C 190°C 24°C 24°C
ZP(HP)-8-6-6-SC/WC 2 3 4 6 10 9 14.0 3.5 12 3.5 5
ZP(HP)-16-10-10-SC/WC 1.5 2.5 3 5 10.5 11 11.4 4 11 3 5
ZP(HP)-32-10-10-SC/WC 3 5 6 8 12 10 12.5 7 20 6 10
ZP(HP)-32-15-15-SC/WC 2 3 4 6 10 8 15.6 6 16 5 8
ZP(HP)-32-20-20-S/WC 1.5 2.3 2.5 4 6 5 25.0 2 9 3 4.5
ZP(HP)-44-15-15-SC/WC 3 4 6 9 13 11 11.4 6 15 5 8
ZP(HP)-44-20-20-S/WC 2 3 4 6 8 8 15.6 3 12 3 4.5
ZP(HP)-64-15-15-SC/WC 4 5 6 9 16 12 10.4 8 20 6 10
ZP(HP)-64-20-20-S/WC 2.5 3.5 4.5 6.5 9 9 14.0 3.5 13 3.5 5
ZPS(HP)-80-20-20-S/WC 3 4.5 5.5 7.5 11.5 12 10.4 5 17 6 10
Ca
Ca
Ca
Ca
Ca
sc
sc
sc
sc
sc
ad
ad
ad
ad
ad
e
e
e
e
e
7
-7
7
7
0
0
0
0
0
°C
C
C
C
C
t
t
t
t
t
o
o
o
o
o
19
19
19
19
9
0°
0
0
0
0
C
C
C
C
C
Cooling Performance
Cooling
Heating Performanc
e
Cascade -70°C to 190°C
Cooling Performance Cooling Heating Performance
with Empty Chamber in Minutes from: Rate ² with Empty Chamber in Minutes from:
24°C 85°C °C / min 24°C -34°C -68°C
Model -18°C -34°C -40°C -54°C -68°C -40°C 93°C 190°C 24°C 24°C
ZP-8-2-2-H/AC 5 8 9 12 20 18 7.0 10 30 10 15
ZP-8-3.5-3.5-SC/AC 3 5 6 10 16 14 9.0 3.5 12 3.5 5
ZP-16-2-2-H/AC 6 10 12 17 25 25 5.0 15 50 12 22
ZP-16-3.5-3.5-SC/AC 5 8 11 16 23 25 5.0 10 30 6 12
ZP-16-6-6-SC/WC 4 5 6 9 15 13 9.6 10 30 6 12
ZP-32-2-2-H/AC 10 16 20 28 38 40 3.1 20 72 15 25
ZP-32-3.5-3.5-SC/AC 8 13 16 23 33 30 4.2 10 35 8 15
ZP-32-6-6-SC/WC 5 8 10 15 23 20 6.3 10 35 8 15
ZP-44-3.5-3.5-SC/AC 13 22 26 40 60 45 2.7 20 60 15 25
ZP-44-6-6-SC/WC 8 12 15 22 32 32 4.0 20 60 15 25
ZP-44-10-10-SC/WC 4 6 7 10 16 15 8.3 8 25 7 10
ZP-64-3.5-3.5-SC/AC 15 25 30 42 65 65 2.0 25 75 20 30
ZP-64-6-6-SC/AC 10 15 20 26 36 36 3.5 25 75 20 30
ZP-64-10-10-SC/WC 5 6 8 13 22 18 7.0 10 30 8 12
ZPS-80-3.5-3.5-SC/WC 18 30 36 50 70 70 1.8 30 80 25 35
ZPS-80-6-6-SC/WC 12 20 23 33 45 45 2.7 30 80 25 35
ZPS-80-10-10-SC/WC 7 9 10 16 29 30 4.2 15 40 12 18
ZPS-80-15-15-SC/WC 5 7 8 11 19 20 6.2 12 31 10 15
