GENERAL DESCRIPTION
Page 2-15
Table 2-4. ZP Load Capacity and Electrical Requirements Cont’d
Live Load Capacity Electrical Power Requirements
Watts Full Load Amps ¹
Model -18°C -34°C -40°C -54°C -68°C 208/230V, 1 Phase 208/230V, 3 Phase 460V, 3 Phase
ZP-8-2-2-H/AC - - 1200 900 600 49 36 -
ZP-8-3.5-3.5-SC/AC - - 1700 1200 750 - 48 29
ZP-16-2-2-H/AC - - 1800 1200 600 49 36 -
ZP-16-3.5-3.5-SC/AC - - 2000 1600 1000 - 48 29
ZP-16-6-6-SC/WC - - 3000 2400 1500 - 65 29
ZP-32-2-2-H/AC - - 1500 1100 600 49 36 -
ZP-32-3.5-3.5-SC/AC - - 2000 1600 1000 - 48 29
ZP-32-6-6-SC/WC - - 3000 2400 1500 - 65 29
ZP-32-10-10-SC/WC - - 4500 3500 1700 - - 45
ZP-32-15-15-SC/WC - - 5500 4500 2500 - - 53
ZP-44-3.5-3.5-SC/AC - - 1700 1300 700 - 48 29
ZP-44-6-6-SC/WC - - 2700 2100 1200 - 65 29
ZP-44-10-10-SC/WC - - 4500 3500 2000 - - 45
ZP-44-15-15-SC/WC - - 5500 4500 3000 - - 53
ZP-64-3.5-3.5-SC/AC - - 1500 1100 500 - 48 29
ZP-64-6-6-SC/WC - - 2500 2100 1000 - 65 29
ZP-64-10-10-SC/WC - - 4500 3500 2000 - - 45
ZP-64-15-15-SC/WC - - 5500 4500 3000 - - 53
ZPS-80-3.5-3.5-SC/WC - - 1500 1100 500 - 48 29
ZPS-80-6-6-SC/WC - - 2500 2100 1000 - 65 29
ZPS-80-10-10-SC/WC - - 4500 3500 2000 - - 45
ZPS-80-15-15-SC/WC - - 5500 4500 3000 - - 53
Live Load Capacity Electrical Power Requirements
Watts Full Load Amps ¹
Model -18°C -34°C -40°C 208/230V, 1Ph 208/230V, 3Ph 460V, 3Ph
ZP-8-2-SCT/AC 1800 950 725 31 27 -
ZP-8-3.5-SCT/AC 2110 1100 925 - 37 23
ZP-8-6-SCT/WC 2200 1500 1200 - 46 21
ZP-16-3.5-SCT/AC 3000 1700 1300 - 37 23
ZP-16-6-SCT/WC 3600 2300 1800 - 46 21
ZP-16-10-SCT/WC 4000 2500 2000 - - 29
ZP-32-3.5-SCT/AC 3000 1700 1300 - 37 23
ZP-32-6-SCT/WC 3600 2300 1800 - 46 21
ZP-32-10-SCT/WC 6000 3500 2300 - - 29
ZP-32-15-SCT/WC 8000 5000 3000 - - 35
ZP-44-3.5-SCT/AC 2800 1500 1100 - 37 23
ZP-44-6-SCT/WC 3300 2000 1500 - 46 21
ZP-44-10-SCT/WC 6000 3500 2300 - - 29
ZP-44-15-SCT/WC 8000 5000 3000 - - 35
ZP-64-3.5-SCT/AC 2600 1300 800 - 37 23
ZP-64-6-SCT/WC 3100 1800 1300 - 46 21
ZP-64-10-SCT/WC 6000 3500 2300 - - 29
ZP-64-15-SCT/WC 8000 5000 3000 - - 35
ZPS-80-3.5-SCT/AC 2600 1300 800 - 37 23
ZPS-80-6-SCT/WC 3100 1800 1300 - 46 21
ZPS-80-10-SCT/WC 6000 3500 2300 - - 29
ZPS-80-15-SCT/WC 8000 5000 3000 - - 35
LiveLoad Capacity
Electrical PowerRequirements
Cascade -70°C to 190°C
Live L
oad
Capacity
Ele
ctrica
lP
owerRequirements
Tundra® -45°C to 190°C
