CTC Union FRM220-100M User Manual

Example using VID 555 for management, with access via TP port. Normal access to management not allowed.
<< VLAN Tag Status and Configuration >>
<1> TP Frame Egress Type [ Don't Touch Tag ]
<2> FX Frame Egress Type [ Don't Touch Tag ]
<3> CPU Frame Egress Type [ Add Tag ]
<4> TP VLAN Group Index Number [ 0 ]
<5> FX VLAN Group Index Number [ 0 ]
<6> CPU VLAN Group Index Number [ 1 ]
<7> VLAN Ingress Filter [ Enable ]
<8> VLAN Group [ Enable ]
<9> VLAN Group Table Status
TP mem FX mem CPU mem PVID
<0> VLAN Table 0 [ V ] [ V ] [ ] [ 1 ]
<1> VLAN Table 1 [ ] [ ] [ V ] [ 555 ]
<2> VLAN Table 2 [ V ] [ V ] [ ] [ 1 ]
<3> VLAN Table 3 [ V ] [ V ] [ ] [ 1 ]
<4> VLAN Table 4 [ V ] [ V ] [ ] [ 1 ]
<5> VLAN Table 5 [ V ] [ V ] [ ] [ 1 ]
<6> VLAN Table 6 [ V ] [ V ] [ ] [ 1 ]
<7> VLAN Table 7 [ V ] [ V ] [ ] [ 1 ]
<8> VLAN Table 8 [ V ] [ V ] [ ] [ 1 ]
<9> VLAN Table 9 [ V ] [ V ] [ ] [ 1 ]
<a> VLAN Table 10 [ V ] [ V ] [ ] [ 1 ]
<b> VLAN Table 11 [ V ] [ V ] [ ] [ 1 ]
<c> VLAN Table 12 [ V ] [ V ] [ ] [ 1 ]
<d> VLAN Table 13 [ V ] [ V ] [ ] [ 1 ]
<e> VLAN Table 14 [ V ] [ V ] [ ] [ 1 ]
<f> VLAN Table 15 [ V ] [ V ] [ ] [ 1 ]
19

CTC Union FRM220-100M Specifications

General

Brand	CTC Union
Model	FRM220-100M
Category	Media Converter
Language	English
