Rear Axle and Brake 6
91
3) Turn the rod back 1/2 turn and fix with locknut.
Arm
Rod
"J"
Locknut
Plate
Setmeasurement(128{5.04})
(24{0.945})
mm{in}
Differentiallockpedal
"B"
GZ3W25-019
