Front Axle 7
103
5. Disassemble the pinion assembly.
1 Bolt 2 Bracket Holder
3O-ring 4Bolt
5 Shim D 6 O-ring
7 Nut 8 Bush
9 O-ring 10 Bearing
11 Bearing 12 Pinion Shaft
13 Oil Seal 14 Case
Grease
Adjustment
Grease
Grease
Grease
9
9
7
8
7
8
5
4
3
10
10
14
13
13
11
12
12
6
1
2
GZ3W26-017
