Front Axle 7
105
7. Disassemble the knuckle arm.
1 Reamer Bolt 2 Bolt
3Liner F 4O-ring
5 Bush 6 Knuckle Arm
Adjustment
Grease
Grease
5
4
3
6
1
2
GZ3W26-019
www.mymowerparts.com
K&T Saw Shop 606-678-9623 or 606-561-4983
