Front Axle 7
109
(Unit: mm {in})
9 Assembly of Knuckle Arm
1. Adjust the clearance "F" between the knuckle arm and holder to be within 0.05 to 0.20mm {0.002 to 0.008in}
with the thrust liner "F".
2. Apply lithium grease to the bush for the knuckle arm.
(Unit: mm {in})
Item Thickness Usable Limit
Liner "E"
0.10 {0.004} 1135 3016 000
0.40 {0.016} 0731 0002 504
0.80 {0.031} 0731 0002 508
1.00 {0.039} 0731 0002 510
1.20 {0.047} 0731 0002 512
Item Thickness Usable Limit
Thrust
Liner "F"
0.80 {0.031} 1438 1319 600
1.00 {0.039} 1438 1319 500
1.20 {0.047} 1438 1319 400
1.40 {0.055} 1438 1319 300
