Cub Cadet 7530

Hydraulic System 1
15
2 P/C System (Position Control)
No.PartsNo.Parts
1 Knob 2 Nut
3 Spring Pin 4 Screw
5Ring 6Washer
7 Spring 8 Sleeve
9 O-ring 10 O-ring
11 O-ring 12 Ball
13 Spring 14 Lift Arm
15 Pin 16 Screw
17 Power Arm 18 Piston Rod
19 Bush 20 Piston
21 O-ring 22 Ring
7
7
7
7
7
7
Flowcontrolvalve
Liftarm
Adjuster
StopperA
PClever
StopperB
Punchmark
5-10mm{0.197-0.591in}
Upperlimit
Lowerlimit
GZ3W31-011
