1 Hydraulic System
20
2 Disassembly of Hydraulic Lift Case
1. Disassemble the flow control part and piston.
2. Disassemble the lift arm.
PistonRod
Flowcontrol
Piston
GZ3W31-016
Liftarm
Powerarm
Shaft
Hydraulichousing
GZ3W31-017
www.mymowerparts.com
K&T Saw Shop 606-678-9623 or 606-561-4983
