Hydraulic System 1
21
3. Disassemble the control valve and link part.
Bracket
Feedbackarm
P/Carm
PACarm
LinkAssembly
Controlvalve
Block
Arm
P/Carm
P/Clever
Boss
Feedbacklink
Plate
GZ3W31-018
