Specification 6
25
PTO
Rear PTO
Engine Speed rpm 540
Type Independent (G) Combined (H)
Shaft Size 1 to 3/8
Mid PTO
Engine Speed rpm 2000 (Option)
Type Independent (G) Combined (H)
Shaft Size SAE 1in-12teeth
Option Type - -
Hydraulic System
Pump Model Multiple Gear
Discharge
L/min
{gal/min}
27.3 {7.2}
Max. Discharge Pressure
MPa {kgf/
cm
2
, psi}
15.2 { 155, 2205}
Steering Pump Discharge
L/min
{gal/min}
9.6 {2.5}
Steering Pump Max. Discharge Pressure
MPa {kgf/
cm
2
, psi}
10.3 { 105, 1493}
Max. Dynamic Lift (Ball End Side) N {kgf, lbs} 10149 {1035, 2282}
Max. Dynamic Lift (24in Backward) N {kgf, lbs} 7649 {780, 1719}
Dynamic Lift Control Type Standard Position
Option Draft
Auxiliary Valve Option (1)
Hydraulic Press. Extracting Block Standard (Chassis Side)
3P Link
Type of Link 1
Expanding Stabilizer Standard
Adjustment of Right-side Lift Rod Turn Buckle
Capacity
Cooling Water
Radiator L {gal} 5.5 {1.5}
Sub Tank L {gal} 0.33 {0.09}
Engine Oil L {gal} 4.2 {1.1}
Transmission Oil L {gal} 29 {7.7} 32 {8.5}
Front Axle Oil L {gal} 4.0 {1.1}
Fuel L {gal} 27 {7.1}
Option
Deck Type Semi Flat Deck
Pedal Type Floor Mounting
Seat Cub Cadet
Steering Device Hydraulic Power Steering
Tilt Steering Standard (3 Stages)
Protection Guard Standard
Tire
AG Tire (Front Wheel/Rear Wheel) 7 to 14/9.5 to 24 7 to 16/11.2 to 24
Tire for Lawn (Front/Rear Wheel)
25 × 8.50 to 14/
13.6 to 16
212/80D15/355/80D20
Industrial Tire (Front/Rear Wheel) -
Model 30hp GEAR 32hp HST
