6 Specification
26
* This specification is subject to be revised in accordance with modification.
Fittings
Load Weight kg {lbs} 408 {900}
Vehicle Gross Weight kg {lbs} 2200 {4850}
Shared Load
Front Wheel kg {lbs} 1350 {2975}
Rear Wheel kg {lbs} 1350 {2975}
Electrical Equipment
Battery Cub Cadet
Panel
Fuel Meter Standard
Hour/Tachometer Standard
Heat Indicator Standard
Charge Lamp Standard
Oil Lamp Standard
Power Key Interception Standard
Horn Option
Head Lamp Standard
Tail Lamp Standard
Direction Indicator (Hazard Lamp) Standard
Reflector Standard
Rear Working Lamp Option
Glow System Standard
7-Pole Connector N/A
Others
Engine Hand Throttle Standard
Accelerator Pedal Standard N/A
Exhaust Box Inner Side Cover
Seat Cub Cadet
Seat with Suspension Cub Cadet
Seat Belt Standard
Tools N/A
Tool Box N/A
SMV Emblem N/A (Bracket Only)
Running Speed
km/h
9.5 to 24 355/80D20
Drive - 1 / Reverse-Drive - 1 1.4 {0.9}/1.2 {0.8} L Range
2 / 2 2.1 {1.3}/1.7 {1.1}
0 to 4.7 {2.9}/0 to 2.4 {1.5}
3 / 3 3.1{1.9 }/2.6 {1.6}
4 / 4 4.7 {2.9}/3.9 {2.4} M Range
5 / 5 5.2 {3.2}/4.3 {2.7}
0 to 8.6 {5.3}/0 to 4.3 {2.7}
6 / 6 7.3 {4.6}/6.1 {3.8}
7 / 7 11.1 {6.9}/9.3 {5.8} H Range
8 / 8 16.8 {10.4}/14.0 {8.7}
0 to19.2 {11.9}/0 to9.6 {6.0}
Max. / Max. 18.1{11.3 }/15.2 {9.4}
0 to 20.6 {12.8}/0 to 0.3 {6.4}
Model 30hp GEAR 32hp HST
