1 Maintenance Standard
2
(Unit : mm{in})
Item Standard Value Limit Value Remarks
Clearance of shift fork
Clearance bet. main gearing fork and gear gap
0.35 to 0.65
{0.014 to 0.026}
1.00
{0.039}
Clearance bet. sub gearing fork and gear gap
0.35 to 0.65
{0.014 to 0.026}
1.00
{0.039}
Clearance bet. shift piece 2WD 4WD and gear gap
0.20 to 0.40
{0.008 to 0.016}
1.00
{0.039}
Clearance bet. PTO fork and gear gap
0.35 to 0.65
{0.014 to 0.026}
1.00
{0.039}
Clearance bet. shuttle fork and gear gap
0.35 to 0.65
{0.014 to 0.026}
1.00
{0.039}
Backlash for transmission spur gear
0.10 to 0.30
{0.004 to 0.012}
0.35
{0.014}
Rear Axle Brake
Backlash
Backlash for pinion gear and side gear
0.25 to 0.35
{0.01 to 0.014}
Backlash for pinion shaft and deferential ring gear
0.10 to 0.30
{0.004 to 0.012}
Lateral clearance of deferential assembly
0 to 0.10
{0 to 0.004}
Endplay of rear axle shaft and case
0.15 to 0.35
{0.006 to 0.014}
Backlash for deferential shaft and final gear
0.10 to 0.30
{0.004 to 0.012}
0.50
{0.020}
Clearance bet. axle case and shifter
0.20 to 0.60
{0.008 to 0.024}
Free play for brake pedal
35 to 45
{1.38 to 1.77}
Difference in
left/right :
below 3.0
{0.12}
Thickness of Brake Disc 2.8{0.11} 2.2{0.087}
Brake pedal Clearance bet. bush and shaft
0.04 to 0.12
{0.0016 to 0.005}
0.50
{0.020}
Front Axle
Backlash
Backlash for pinion gear and side gear
0.10 to 0.30
{0.004 to 0.012}
Backlash for pinion shaft and deferential gear
0.25 to 0.35
{0.01 to 0.014}
Lateral clearance of deferential assembly
0 to 0.10
{0 to 0.004}
Backlash for deferential shaft bevel gear 14T and kingpin
shaft bevel gear 18T (upper)
0.20 to 0.40
{0.008 to 0.016}
Backlash for axle shaft bevel gear 32T and kingpin shaft
bevel gear 12T (lower)
0.20 to 0.40
{0.008 to 0.016}
