2 Installation and Removal of Engine Parts
26
7 Cleaning and Changing of Fuel Filter
Clean it every 50 hours and change it every 200 hours.
1. Position the cock to "OFF".
2. Remove the cup and wash it with clean gas-oil.
3. Remove the element and clean or change it.
4. Install the O-ring, element and cup.
5. Remove the air following the air purge procedure.
8 Air Removal of Fuel Line
1. Open the fuel cock.
2. Loosen the air vent screw "A". When fuel with no
mixture with bubbles starts coming out, tighten the
air vent screw.
O-ring
O-ring
Element
Retainingnut
Cup
"Open"
"Close"
PR8W3-031
"Open"
"Close"
GZ3W21-047
"Close"
"Open"
"A"
GZ3W21-048
