4‐48
Engine
•
Drive Shaft coupling
•
Washer
•
Nut(1)
Note:
Use the coupling gear / middle shaft
tool (2) to hold the drive shaft coupling.
Nut Torque 97 Nm or 71 ft lbs
Install the middle drive shaft
•
Tighten the middle pinion gear nut
(1)
to 145 Nm or 107 ft lbs
•
Lock the threads with a drift punch.
