Cub Cadet Challenger 550 User Manual

2-20
Specifications
ENGINE TIGHTENING TORQUES
Part to be Tightened
Part
Name
Thread
Size
Qty
Torque
Nm
Torque
Ft Lbs
Shift arm
Bolt
6mm
1
14
10
Shift rod locknut (select lever unit)
Nut
8mm
1
15
11
LH
Shift rod locknut (shift arm side)
Nut
8mm
1
15
11
Select lever unit
Bolt
8mm
3
15
11
Plug (right crankcase)
Plug
14mm
1
18
13
Water pump assembly
Bolt
6mm
2
10
7.2
Water pump housing cover
Bolt
6mm
2
12
8.7
Coolant drain bolt
Bolt
6mm
1
10
7.2
Coolant inlet joint
Bolt
6mm
2
10
7.2
Coolant outlet joint
Bolt
6mm
2
10
7.2
Air bleed bolt (coolant outlet joint)
Bolt
6mm
1
8
5.9
Coolant reservoir
Bolt
6mm
2
8
5.9
Radiator bracket and frame
Bolt
6mm
4
8
5.9
Fuel pump
Bolt
6mm
2
8
5.9
Fuel tank
Bolt
8mm
2
22
16
Muffler stay
Bolt
6mm
2
11
8
Muffler and exhaust pipe
Bolt
8mm
1
20
14
Muffler bracket and muffler
Bolt
8mm
1
20
14
Muffler bracket and frame
Bolt
8mm
2
20
14
Muffler damper and muffler
Bolt
6mm
1
10
7.2
Muffler damper and frame
Bolt
6mm
1
10
7.2
Exhaust pipe
Nut
8mm
4
14
10
Air duct assembly 1
Bolt
6mm
2
7
5.1
Air duct assembly 2 and left protector
Bolt
6mm
1
7
5.1
Air duct assembly 2 and frame
Bolt
6mm
1
7
5.1
Gear position switch
Bolt
5mm
2
7
5.1
Thermo switch 1 (cylinder head)
—
1/8
1
8
5.8
Thermo switch 3 (radiator)
—
18mm
1
28
20
Reverse switch
—
10mm
1
20
14
Engine ground lead
Bolt
6mm
1
10
7.2
Starter motor and engine
Bolt
6mm
2
10
7.2
