18
2-20 Included Weight Kit Installation
Installation Instructions For All Tank SZ Models:
— Slide (1) weight bar (D) per side into position from above. Each weight bar (D) should be positioned with longer
— Slide weight clamp (C) into position as shown in Figure 2-20b. Fasten weight clamp (C) loosely with
— Tighten mower’s steering rack bolts (B) to secure weight bars (D) with weight clamp (C).
— Remove the front caster guard (A).
— Remove (2) bolts (B) from mower’s steering rack.
mowers’s steering rack bolts (B).
— Refer to Figure 2-20a & 2-20b.
length vertical.
— Replace mower’s front caster guard (A).
— Remove (2) carriage bolts (R) from backside of mower’s front caster area. Keep existing nuts (B) and replace
— Tighten bolts (C) to secure weight bars (F) with weight clamp (E).
— Slide weight clamp (E) into position over loosened bolts as shown in Figure 2-21b.
carriage bolts with (2) 3/8”-16 x 1-1/4” hex bolts (C) P#(K1192) and (2) flat washers (D) P#(K0047). Loosely tighten
— Slide (1) weight bar (F) per side into position from above. Each weight bar (D) should be positioned with longer
length vertical.
bolts with existing nuts (B). See Figure 2-21c for carriage bolt removal locations circled (R) .
Installation Instructions For Tank LZ Models w/ 48” Decks:
— Refer to Figure 2-20c & 2-20d.
— Remove mower’s front caster guard (A).
— Replace the mower’s front caster guard (A).
Please Note: The images below may not fully
represent your mower as some parts have been
removed/hidden for visual clarity during installation.
Figure 2-20a
Figure 2-20a
A
C
D
Figure 2-20c Figure 2-20d
A
E
B
B
R
R
F
B
B
D
F
C
D
C
D
